| Great Western Railway - Collett Stock |
|
|
|
Collett Stock is grouped by general type then by diagram please notice the added notes
|
|
| Corridor Brake Composite |
BCK |
Diag.E114 |
25 Built |
| Flat ends |
57.0 * 9.0 |
|
| Lot 1323 1925 |
|
|
| 7976 | | | | IU 079027 | Didcot Railway Centre |
|
| Full Brake |
BG/PMV |
Diag.K36 |
7 Built |
| Ex Ambulance |
57.0 * 9.0 |
|
| Lot 1344 1925 |
|
|
| 1159 | | | | KDW150294 | Didcot Railway Centre |
|
| |
|
Bow ended stock |
| Corridor Third |
TK |
Diag.C54 |
274 Built |
|
58.4 1/5 * 9.0 |
8 Comp 64T 2L 29 Ton |
| Lot 1352 1925 |
7ft Bogies |
|
| 4546 | | | | IU 060903 | Severn Valley Railway |
| 4553 | | | | KDW150207 | Didcot Railway Centre |
| Lot 1369 1926 |
|
|
| 4786 | | | | DW150208 | Severn Valley Railway |
| Lot 1372 1927 |
|
|
| 4872 | | | | DW150209 | Severn Valley Railway |
| Lot 1374 1927 |
|
|
| 4886 | | Part Of Body Only | DW150201 | Severn Valley Railway |
| Lot 1383 1928 |
|
|
| 5043 | | | | DW150301 | Severn Valley Railway |
| 5085 | | | | DW150200 | Didcot Railway Centre |
 |
 |
|
| Corridor Brake Third |
BTK |
Diag.D95 |
118 Built |
|
58.4 1/5 * 9.0 |
4 Comp 32T 1L |
| 4mm model available from Hornby |
| Lot 1384 1928 |
7ft Bogies |
|
| 5102 | | | | DW150234 | Northampton Railway |
| 5131 | | | | DW150246 | Bodmin & Wenford Railway |
|
| Corridor Composite |
CK |
Diag.E132 |
51 Built |
|
57.4 1/5 * 9.0 |
4F Comp 3T Comp 24F 24T 2L ?? Ton |
| 4mm model available from Hornby |
| Lot 1382 1928 |
7ft Bogies |
|
| 6045 | | | | DW150293 | Severn Valley Railway |
|
| Corridor Brake Composite |
BCK |
Diag.E128 |
22 Built |
|
58.4 1/5 * 9.0 |
?F Comp ?T Comp ??F ??T ?L ?? Ton |
| Lot 1350 1926 |
7ft Bogies |
|
| 6515 | | | | | Tyseley |
|
| Restaurant Composite |
RCO |
Diag.H33 |
4 Built |
|
58.4 1/5 * 9.0 |
?? Ton |
| 4mm model available from Hornby |
| Lot 1349 1925 |
7ft Bogies |
|
| 9580 | | | | KDW150266 | East Lancs. Railway |
|
| Ex Artic Restaurant Third |
RTO |
Diag.H52 ex H32 |
6 Built |
|
60.3 (ex 50.6 3/4) * 9.0 |
7 Bays 56T 2L |
| Lot 1359 1925 ReBuilt 1936 |
7ft Bogies |
|
| 9653 | ex 10020 | | | DW150032 | Severn Valley Railway (N) |
| 9654 | ex 10036 | | | DW150033 | Severn Valley Railway (N) |
 |
 |
|
| Brake Third |
BT |
Diag.D101 |
24 Built |
|
58.2 * 9.0 |
? Comp ??T |
| Lot 1392 1928 | | |
| 5539 | | | | DW150323 | Steamport/Southport |
|
| Brake Third |
BTK |
Diag.104 |
17 Built |
| Bow Ended |
58.4 1/2 * 8.10 1/4 |
? Comp ??T ?L |
| Lot 1412 1929 |
|
|
| 5240 | | | | KDW150272 | Severn Valley Railway |
|
| Auto Trailer |
|
Diag.A27 |
12 Built |
| Built with 2 Cabs |
59.6 * 9.0 |
64T + 8 Tip up 0L 30 Ton |
| Lot 1394 1929 |
7ft Bogies |
|
| 160 | | Part Of Body Only | | Severn Valley Railway |
| 163 | | | | | Cambrian Railway |
| 167 | | | | | Llangollen Railway |
| 169 | | | | IU 064749 | West
Somerset Railway |
|
| Auto Trailer |
|
Diag.A28 |
10 Built |
| Built with 2 Cabs |
62.8 * 9.0 |
64T + 8 Tip up 0L 30 Ton |
| Lot 1410 1930 |
9ft Bogies |
|
| 174 | | | | DW150313 | Llangollen Railway |
| 178 | | | | | Unknown (Ex Dean Forest Railway) |
|
| Auto Trailer |
|
Diag.A30 |
10 Built |
|
62.8 * 9.0 |
64T + 8 Tip up 0L 30 Ton |
| 4mm model available from Hornby ex Airfix |
| Lot 1480 1933 |
9ft Bogies |
|
| 190 | | | | | Didcot Railway Centre |
|
| Saloon Brake Third |
BTO |
Diag.G58 |
10 Built |
| Bow ended |
58.4 1/5 * 9.0 |
2 Sal (20) 1 Comp 44T 1L ?? Ton |
| Lot 1400 1929 |
7ft Bogies |
|
| 9103 | | | | IU 079124 | Severn Valley Railway |
|
| Saloon Brake First |
BFO |
Diag.G59 |
2 Built |
| Bow ended |
61.4 1/5 * 9.0 |
? Sal ??F ?L ?? Ton |
| Lot 1431 1930 |
9ft Bogies |
|
| 9004 | | | | DE321011 | Tyseley | (ex RFM99053) |
| 9005 | | | | | Steamtown Carnforth |
| In 1961 9005 fitted with Swindon developed prototype B4 bogies. Now refitted with GWR 9ft. |
|
| Restaurant Composite |
RCO |
Diag.H38 |
10 Built |
| Bow ended |
61.4 1/5 * 9.0 |
?? Ton |
| Lot 1451 1930 |
|
|
| 9605 | | | | | Wroughton (National Railway Museum) |
|
| |
|
1932 Diner Twin Set |
| Restaurant First With Kitchen |
RKFO |
Diag.H39 |
10 Built |
| Bow ended |
61.4 1/5 * 9.0 |
4 Bay 23F ?? Ton |
| Lot 1468 1932 |
9ft Bogies |
|
| 9615 | | | | DW150336 | Severn Valley Railway (Ex BR Plate) |
|
| Restaurant Third |
RTO |
Diag.H40 |
10 Built |
| Bow ended |
61.4 1/5 * 9.0 |
8 Bay 63F 33 Ton |
| Lot 1469 1932 |
9ft Bogies |
|
| 9627 | | | | IU 079112 | Severn Valley Railway (Ex BR Plate) |
|
| Full Brake |
BG/PMV |
Diag.K40 |
50 Built |
| Bow ended |
61.4 1/5 * 9.0 |
|
| Lot 1413 1930 |
|
|
| 1184 | | | | | Didcot Railway Centre |
|
| |
|
Super Saloons |
| Open First |
FO |
Diag.G60 |
2 Built |
| Bow ended |
61.4 1/5 * 9.7 |
6 Bay 29F 2L 35 Ton |
| Lot 1471 1931-2? |
9ft Bogies |
|
| 9111 | | | KING GEORGE | South Devon Railway |
| 9112 | | | QUEEN MARY | Didcot Railway Centre (Ex BR GWS99507) |
|
| Open First |
FO |
Diag.G61 |
6 Built |
| Bow ended |
61.4 1/5 * 9.7 |
6 Bay 29F 2L (* 4 Bay 20F 1L) ?? Ton |
| Lot 1471 1932 |
9ft Bogies |
|
| 9113 | | | PRINCE OF WALES | Didcot Railway Centre |
| 9116 | | | DUCHESS OF YORK | Torbay & Dartmouth Railway |
| 9118 | | | PRINCESS ELIZABETH | Didcot Railway Centre (Ex BR GWS9950?) |
| (9117/8 Were rebuilt with a kitchen) -> H46 |
|
| |
|
Mid 1930's Flat Ended Stock |
| Corridor Third |
TK |
Diag.C67 |
155 Built |
|
57.0 * 9.0 |
8 Comp 64T 2L 30 Ton |
| Lot 1509 1935 |
9ft Bogies |
|
| 5813 | | | (Brown) | DW150030 | Dean Forest Railway |
| 5848 | | | (Maroon) | DW150324 | Dean Forest Railway |
| 5856 | | | | DW150??? | Wye Valley Sta. Mus. Static Restaurant |
| 5863 | | | | DW150325 | Dean Forest Railway |
| Lot 1527 1935 | 9ft Bogies | |
| 5929 | | | | DW150029 | Dean Forest Railway |
| 5952 | | | | | Didcot Railway Centre (Ex BR GWS9950?) |
 |
|
| Corridor Brake Third |
BTK |
Diag.D116 |
19 Built |
|
57.0 * 9.0 |
4 Comp 32T 1L 30 Ton |
| Lot 1490 1933 |
9ft Bogies |
|
| 5787 | | | | IU 079089 | Didcot Railway Centre |
|
| Brake Third (Non Corridor) |
BT |
Diag.D117 |
66 Built |
|
57.0 * 9.0 |
? Comp ??T 0L ?? Ton |
| Lot 1493 1934 |
|
|
| 5500 | | | | IU 071343 | Pontypool & Blaenavon Railway |
|
| Corridor Brake Third |
BTK |
Diag.D118 |
33 Built |
|
57.0 * 9.0 |
4 Comp 32T 1L 30 Ton |
| Lot 1510 1934 |
|
|
| 5804 | | | | DW150304 | Plym Valley Railway |
| Lot 1514 1934 |
9ft Bogies |
|
| 5883 | | | | IU 079135 | Severn Valley Railway |
|
| Corridor Brake Composite |
BCK |
Diag.E148 |
40 Built |
|
57.0 * 9.0 |
2F Comp 4T Comp 12F 32T 2L 30 Ton |
| Lot 1508 1934 |
9ft Bogies |
|
| 6912 | | | Chassis Only | | West Somerset Railway (Chassis for 8242) |
| 6913 | | | | IU 079134 | Severn Valley Rly (BR SVR99240) |
|
| Restaurant Buffet |
RB |
Diag.H41 |
2 Built |
| Quick Lunch Bar Car |
57.0 * 9.0 |
A few stools 0L 35 Ton |
| Lot 1518 1934 |
|
|
| 9631 | | | | | Severn Valley Railway (N) |
|
| Full Brake |
BG |
Diag.K41 |
60 Built |
|
57.0 * 9.0 |
28 Ton |
| Lot 1512 1934 |
|
|
| 111 | | | | | Didcot Railway Centre |
| Lot 1535 1935 |
|
|
| 184 | | | | ADB975157 | Cholsey & Wallingford |
| 185 | | | | ADB975158 | Glos. Warwicks. Railway |
| Lot 1562 1936 |
|
|
| 150 | | | | | Fisons (BR FA99901) |
|
| Restaurant Kitchen First (Centenary) |
RKFO |
Diag.H43 |
2 Built |
| Bow ended |
61.4 1/5 * 9.7 |
4 Bay 24F 1L 43 Ton |
| Lot 1540 1935 |
|
|
| 9635 | | | | | Didcot Railway Centre |
 |
|
| Auto Trailer |
|
Diag.A26 |
5 Built |
|
70.0 * 9.0 |
?? Ton |
| (ReBuilt from steam railmotor 93 Diag.R Lot 1142 1908 16 Built |
| Lot 1542 1936 |
|
|
| 212 | | | | | Didcot Railway Centre |
|
| Open Third (Excursion) |
TTO |
Diag.C74 |
27 Built |
|
60.0 * 9.0 |
8 Bay 2 Sal 64T 2L 30 Ton |
| Lot 1575 1937 |
|
|
| 1285 | | | | | South Devon Railway |
| 1289 | | | | | Didcot Railway Centre (Ex BR GWS99500) |
| 1295 | | | | | South Devon Railway |
|
| |
|
Sunshine Coaches |
| Corridor Third |
TK |
Diag.C77 |
165 Built |
|
60.11 1/4 * 8.11 |
8 Comp 64T 2L 31 Ton |
| Lot 1593 1938 |
9ft Bogies |
|
| 1086 | | | * | IU 079154 | Severn Valley Railway (Ex BR Plate) |
| 1087 | | | * | IU 079158 | Severn Valley Railway (Ex BR Plate) |
| 1111 | | | * | IU 079159 | Didcot Railway Centre (Ex BR GWS9950?) |
| 1116 | | | * | IU 079157 | Severn Valley Railway (Ex BR Plate) |
| 1133 | | | Chassis for 9006 War Damaged | | National Railway Museum |
| 1146 | | | * | IU 079153 | Severn Valley Railway (Ex BR Plate) |
| Lot 1623 1940 |
9ft Bogies |
501- 595 |
| 536 | | | * | IU 079152 | South Devon Railway (GWS loan) (Ex BR GWS9950?) |
| * All C77 Ex Swindon Works Test Train |
 |
|
| Corridor Brake Third |
BTK |
Diag.D127 |
79 Built |
|
60.11 1/4 * 8.11 |
4 Comp 32T 1L 30 Ton |
| Lot 1594 1938 |
9ft Bogies |
|
| 1645 | | | (B+C) | IU 079170 | South Devon Railway |
 |
|
| Corridor Composite |
CK |
Diag.E158 |
96 Built |
|
59.10 * 8.11 |
4F Comp 3T Comp 24F 24T 2L 31 Ton |
| Lot 1621 1940 |
9ft Bogies |
7301-7340 |
| 7313 | | | | IU 079155 | Didcot Railway Centre (Ex BR GWS9950?) |
|
| Corridor Composite |
CK |
Diag.E162 |
20 Built |
|
59.10 * 8.11 |
4F Comp 3T Comp 24F 24T 2L 31 Ton |
| Lot 1639 1941 |
9ft Bogies |
7271-7290 |
| 7284 | | | | IU 079156 | Severn Valley Railway |
| 7285 | | | | | Didcot Railway Centre |
|
| Corridor Brake Composite |
BCK |
Diag.E159 |
55 Built |
|
60.11 1/4 * 8.11
| 2F Comp 4T Comp 12F 32T 2L |
| Lot 1589 1938 |
9ft Bogies |
|
| 6562 | | | | | Severn Valley Railway |
| 6705 | | | | | American Steam Town Virginia |
| Lot 1640 1941 |
|
7357-7371 |
| 7362 | | | | IU 079151 | Swindon Works |
| 7371 | | | | | Didcot Railway Centre (Ex BR Plated) |
